Map

Profile

Location British Columbia, Canada
Commodities Primary Copper, Gold
Commodities Secondary Molybdenum, Silver, Lead, Zinc, Nickel
Total Current Year Production Period Ended December 31, 2017
Copper; lbs 74,636
Gold, ounces 194,410
Silver; ounces 312,394
Total Known Current and Historical Production 1909 – 2017
Copper; lbs 1,172,811,446
Gold, ounces 7,550,535
Silver; ounces 237,087,210
Molybdenum; lbs 29,982,832
Lead; lbs 74,369,051
Zinc; lbs 22,468,504
Total Known Compliant Reserves
Proven & Probable
Copper; lbs 25,445,638,000
Gold, ounces 62,219,000
Silver; ounces 421,093,000
Molybdenum; lbs 1,000,540,000
Lead; lbs 132,400,000
Zinc; lbs 734,000,000
Total Known Compliant Exclusive Resources
Measured & Indicated
Copper; lbs 20,424,512,000
Gold, ounces 70,488,000
Silver; ounces 394,478,574
Molybdenum; lbs 640,280,000
Lead; lbs 52,910,000
Zinc; lbs 391,723,000
Nickel; lbs 4,057,000,000
Cobalt; lbs 253,080,000
Inferred
Copper; lbs 44,268,298,300
Gold, ounces 83,404,396
Silver; ounces 636,395,200
Molybdenum; lbs 1,700,260,000
Lead; lbs 200,529,600
Zinc; lbs 1,136,300,000
Nickel; lbs 4,304,600,000
Cobalt; lbs 279,803,000
Total Known Endowment* 1909-2017
Copper; lbs 91,311,259,746
Gold, ounces 223,661,931
Silver; ounces 1,689,053,984
Molybdenum; lbs 3,371,062,832
Lead; lbs 460,208,651
Zinc; lbs 2,284,491,504
Nickel; lbs 8,361,600,000
Cobalt; lbs 532,883,000

Total Known Endowment includes current and historical production and compliant reserves and resources
Data compiled from DigiGeoData database, British Columbia Minfile, technical reports and corporate websites
DigiGeoData has compiled this information using best practices and does not warranty the completeness or accuracy.
All data should be checked and verified before use

Click to go to the Map Interface

History

Prospectors, or would-be prospectors, were first drawn to this area in 1861 for the Stikine Gold Rush. This rush is said to have attracted over 800 gold seekers. Years later in the late 1890s, another wave of prospectors passed through the area to participate in the Great Klondike Gold Rush. Some traveled by boat up the rivers, such as the mighty Stikine, however, much of the northwest BC was deemed either inaccessible or covered predominantly by snow and/or ice.

Lode gold was first discovered by prospectors in the Stewart area around the turn of the century. Over the years, as many as 50 producers (mostly small ones) operated annually in the Stewart region; the best example being the Premier and Big Missouri mines.

However, when World War II came along, most operations ceased. It wasn’t until the 1960s that major mining companies began exploring for large tonnage, low-grade porphyry copper deposits. They were very successful in discovering several deposits (e.g. Galore Creek, Schaft Creek and Red Creek). However, prospecting during the 1970s and early 1980s was intermittent, and none of these large deposits were moved forward to a development stage.

In late 1988, Prime Resources announced the discovery of the world-class, high-grade Eskay Creek gold-silver deposit. Eskay Creek went on to become one of the world’s most prolific mines producing almost 3.3 million ounces of gold and 159 million ounces of silver over its lifetime.
In 1990, mineral exploration reached its peak in the Golden Triangle, with some $100 million being spent, including about 40 drilling programs. Some 40 companies were active in the areas, about half “majors” and half “juniors”. In 1990, the Vancouver Stock Exchange recorded daily volume records.
During a nine-year period starting in 1991, the Snip mine produced over 1 million ounces of gold and almost 400 thousand ounces of silver

2003 saw a significant rebirth in ground acquisition in the area. In 2005, with the new MTO staking system, another wave of staking occurred in the area, where exploration expenditures were estimated at $90 million, including $50 million at Galore Creek.

Over the past ten years the Golden Triangle has been the focus of increased exploration
The Golden Triangle currently has two producing mines; Red Chris and Brucejack.

Five proposed new mines are under review including Galore Creek, Kitsault, KSM, Red Mountain and Schaft Creek.
New deposits have been found, current deposits expanded and past producers such as Premier, Snip and Eskay Creek are under going a fresh new look.

Geology

The Golden Triangle lies within the Stikine Arch geological province which includes a northerly trending succession of Upper Triassic (Stuhini Group) to Jurassic (Hazelton Group) volcanic and sedimentary rocks. These are underlain in part by Paleozoic marbles and other sedimentary units.

All have been intruded by Mesozoic or Tertiary intrusive rocks and cut by extensive fault zones.

The Stikine Arch has undergone pervasive large-scale deformation related to late Jurassic orogenesis. There is a strong (+/- genetic) relationship between lower Jurassic volcanism and early Jurassic intrusive events (late 190Ma to early 200Ma), especially with respect to the formation of the many porphyry deposits.

At the Eskay Creek subaqueous volcanic-associated massive sulphide deposit, the main mineralizing event occurred in the late Jurassic (approx. 177Ma).

Older Paleozoic volcanogenic massive sulphide mineralization formed in the Devonian-Mississippian era (approx. 350Ma)

The Golden Triangle is bounded on the east by the younger Bowser Basin sediments.

Resources

In Situ Reserves and Resources

In Situ Reserves and Resources

In Situ Reserves and Resources

In Situ Reserves and Resources

In Situ Reserves and Resources

In Situ Reserves and Resources

Production

Production History
